15
ITEM QTY PART NUMBER DESCRIPTION
1 4 MNLW16 M16 NORDLOCK WASHER
2 8 M9331240N M12 X 40MM BOLT + NUT
3 4 M9331250N M12 X 50MM BOLT + NUT
4 4 M9331650N M16 X 50MM BOLT + NUT
5 2 M9332060N M20 X 60MM BOLT + NUT
6 2 M9332450N M24 X 50MM BOLT + NUT
7 1 MAT10003 BLADE BAR CARRIER
8 2 MAT10025 SLIDE
9 3 MAT10038 LYNCH PIN
10 1 MAT10036 TOP LINK PIN
11 1 MAT10011 PTO SHAFT COVER
12 1 MAT10010 PTO SHAFT COMPLETE
13 1 MAT10031 MAIN TOPPPER BODY
14 1 MAT10018 HEADSTOCK
15 2 MAT10022 BLADE
16 1 MAT10001 BLADE BAR
17 1 MAT10013 GEARBOX
18 3 MAT10035 SHACKLE
19 2 MAT10037 SIDE LINK PIN
20 1 MAT10016 STRAP
Spare Parts —Topper
