12 |
TECHNICAL DATA
Low voltage drive system
(SMPS switching power supply)
Electrical connection: 240V≈50Hz
Output voltage: 35V= 2 A (2,5 A Impulse XL)
Over-current off: 7,5-11,5 A
Over-voltage off: 45 V=
Standby operation: max. 0,5 Watt
Protection: IPX4
Protection class: II
Lifting system force: 2 x 3000 N
Impulse XL 2 x 6000 N
RS adjustment force: 2 x 3000 N
Impulse XL: 3 x 3000 N
Motor running time: 2 min/off 18min
Dimensions: approx.
Impulse 400 (LR 100) 206 x 100 cm
Impulse Ambiente 206 x 100 cm
Impulse XL 206 x 110 cm
Reclining surface (RS): 200 x 90 cm
Impulse XL 200 x 100 cm
Height adjustment: approx.
Impulse 400 (LR 100) 25 (26) up to 82 cm*
Impulse Ambiente 37 up to 84 cm*
Impulse XL 33 up to 83 cm* –
100 mm castors
*measured from the reclining surface frame
Back rest adjustment: 71° reclining angle
for back rest
12 cm mattress compensation
Upper leg adjustment: 43°
Trendelenburg: 14°
Anti-Trendelenburg: 17°
Maximum load: 225 kg
( 190 kg occupant weight
+ 20 kg mattress
+ 15 kg accessories )
Impulse XL 300 kg
( 250 kg occupant weight
+ 25 kg mattress
+ 25 kg accessories )
Weight: approx. 120 kg
Impulse XL approx. 160 kg
