Lens Mounting/Removal 5
Wind up the film advance crank
and fold it into the camera
body. Turn the focusing knob
and fully retract the lens into
the camera body. Then, turn the
lens lock knob (11) until the
triangle mark points to
UNLOCK.
Place the camera so that the
lens mount faces upward and
pinch the lens clamp bracket
(1), press the head toward the
camera body, and move it along
the groove to release the lens
clamp. Now the body cap
and/or lens can be removed.
Insert the lens into the lens
mount so that the lens shutter
cocking lever (4) connects with
the cocking lever on the camera
body. This operation is more
easily performed by cocking the
lens shutter with the fingers and
inserting the lens from the
cocking lever side on the body.
Hook the lens clamp bracket (1)
to its original position, and turn
the lens lock knob
(11)
clockwise to the LOCK
position.
