Maintenance and care
30
Tensioning and changing V-belt
water pump – tension pulley
D Remove fixing bolts À
D Remove lock-nut Á
D Adjust nut  until V-belts have correct
tensions
D Retighten lock-nut and fixing bolts
To change the V-belts turn the adjusting
back and swing the tension pulley in-
wards.
1
2 3
