Commissioning and operation
35
4. Engine room panel MMDS-EP
Motordrehzahl 1835 upm
Motoroeltemperatur 120 C
Ladelufttemperatur 64 C
Kuehlwassertemp. 83 C
Motoroeldruck 4.3 bar
M
1
A
3
ALARMS
Men
PAGE RESET
Prg
Engine run
System Fail.
Alarm
MAN MARINE DIESEL
TYP MMDS−EP
TEST
51.27720−7018
The functions of the keys and of the LCD displays are the same as those on the
MMDS-LC (see operating instructions for MMDS-LC).
Differences to MMDS-LC:
D no ship-specific alarms can be programmed
D additional: −Ignition
−Pre-glow plug
Note on pre-glow plug:
The pre-glow plug is not active in the in-line 6-cylinder engine (D 2876
LE401/404), as this engine is not equipped with a pre-glow system.
On V-engines, pre-glow can be fitted as an option. In ignition position “I”, the
lamp lights up. Wait until the lamp begins to flash, then start.
