Man D 2866 LXE

Technical data
58
Model D 2866 LE, LXE
Design in-line vertical
Cycle 4-stroke Diesel with turbocharger and in-
tercooler
Combustion system Direct injection
Turbocharging Turbocharger with intercooler
Number of cylinders 6
Bore 128 mm
Stroke 155 mm
Swept volume 11 967 cm
3
Compression ratio
D 2866 LE 15.5 : 1
D 2866 LXE 16 : 1
Rating see engine nameplate
Firing order 1–5–3–6–2–4
Valve clearance (cold engine)
Intake 0.25 mm
Exhaust 0.40 mm
Valve clearance changed
Starting from engine no ...5264038.... (in engines with 2-cylinder air compressors
and / or power take-off starting from engine no ...5274086....) (D 2866 LE only)
Intake 0.50 mm
Exhaust 0.50 mm
See instruction label on valve cover
Valve timing D 2866 LE
Intake opens 23° before TDC
Intake closes 37° after BDC
Exhaust opens 60° before BDC
Exhaust closes 30° after TDC
Valve timing D 2866 LXE
Intake opens 23° before TDC
Intake closes 12° after BDC
Exhaust opens 60° before BDC
Exhaust closes 30° after TDC
Fuel system
Injection In-line pump, with flange fastening
Governor All speed type
