Maintenance and care
25
Filling with engine oil
Caution:
Do not add so much engine oil that the oil
level rises above the max. marking on the
dipstick. Overfilling will result in damage
to the engine.
Pour in fresh oil through oil filler neck (1). Ac
cording to variant, this is either on the cylinder
head cover or on the oil pan.
After filling start the engine and let it run for a few
minutes at low speed.
Caution:
If no oil pressure builds up after approx.
10 seconds switch off the engine imme
diately.
Check oil pressure and check that there is no oil
leakage.
Then shut down the engine. After about 20 minu
tes, check the oil level.
D Pull out dipstick
D wipe it with a clean, lintfree cloth
D and push it in again up to the stop
D Pull out dipstick again
The oil level should be between the two notches in
the dipstick and must never fall below the lower
notch. Top up oil as necesary. Do not overfill.
1
1
Oil
?
MIN
MAX
