Page #42 background imageLoading...
Page #42 background image
Technical data
40
Model D 2842 LE 607
Design V-form, 90°
Cycle 4-stroke Diesel with turbocharger and intercooler
Combustion system Direct injection
Turbocharging Turbocharger with intercooler
Number of cylinders 12
Bore 128 mm
Stroke 142 mm
Swept volume 21 930 cm
3
Compression ratio 16,5 : 1
Rating see engine nameplate
Firing order 1-12-5-8-3-10-6-7-2-11-4-9
Valve clearance (cold engine)
Intake 0.50 mm
Exhaust 0.60 mm
Valve timing
Intake opens 24° before TDC
Intake closes 36° after BDC
Exhaust opens 63° before BDC
Exhaust closes 27° after TDC
Fuel system
Injection pump In-line pump
Governor Electronic Diesel Control (EDC) - Model M(S) 5
Injectors six-hole nozzles
Opening pressure of injector
New nozzle holder: 335+8 bar
Used nozzle holder: 320+8 bar
Start of delivery 8°+1° before TDC
