Maintenance and care
114
V-ribbed belt
Danger:
Inspect/replace the V-ribbed belt only
with the engine stopped.
Checking condition
D Check V-ribbed belt for cracks, tears, oil foul
ing, signs of overheating and wear
D Replace damaged V-ribbed belt
Replace V-ribbed belt
Caution:
Danger of crushing!
The V-ribbed belt tensioner is under
spring pre-tension - secure against spring
back!
D Rotate the tensioning pulley of the V-ribbed belt
tensioner (1) clockwise up to the stop and hold
D Remove the V-ribbed belt (2)
D Carefully release the V-ribbed belt tensioning
pulley (1)
D Rotate the tensioning pulley of the V-ribbed belt
tensioner (1) clockwise up to the stop and hold
D Install the new V-ribbed belt (2)
D Carefully release the V-ribbed belt tensioning
pulley (1)
1
2
1
2
1

Man D2862 LE463 Specifications

General

Configuration	V12
Bore	128 mm
Stroke	157 mm
Fuel Type	Diesel
Engine Model	D2862 LE463
Aspiration	Turbocharged
