Page #26 background imageLoading...
Page #26 background image
General Safety Instructions
MAN marine diesel engines D2868 LE4.. / D2862 LE4..
24
Carefully read through the Operating Instructions before starting any work!
This particularly applies to the General Safety Instructions section
and the safety instructions in the various chapters.
2.12 Weight data
Ensure, that when handling the engine and the engine parts listed in the table, suitable lifting equipment is
used.
Description Weight (kg)
Crankcase 500
Crankshaft 135
Flywheel 38
Intercooler 54
Engine slides 189
Oil pan 35
Expansion tank 45
Exhaust manifold parts set 26
Gearbox 561
Flywheel housing 30
Expansion tank 45
Resilient coupling with flange bearing 117
Terminal box 36
Oil filter, switchable 88

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Man D2862 LE496 and is the answer not in the manual?

Man D2862 LE496 Specifications

General IconGeneral
Engine ModelD2862 LE496
Bore128 mm
Stroke157 mm
FuelDiesel
Displacement24.24 l
Power Output882 kW (1200 hp)
Torque5000 Nm
AspirationTurbocharged
Cooling SystemLiquid-cooled
Max. Torque Speed1, 100 - 1, 500 rpm
