Installation and commissioning
MAN marine diesel engines D2868 LE4.. / D2862 LE4..
46
Carefully read through the Operating Instructions before starting any work!
This particularly applies to the General Safety Instructions section
and the safety instructions in the various chapters.
6.3.2 Mounting a gearbox on the flywheel housing
Flywheel
The connection dimensions for the flywheel
1
are
indicated on the installation drawing.
S Remove oil, grease and preservative from the
flywheel.
Flywheel housing
User tip
For bolt tightening torques, see page 56.
Details of the dimensions for the flywheel
housing
1
and the type of threaded connections
for mounting the gearbox are included on the in
stallation drawing.

Man D2862 LE496 Specifications

General

Engine Model	D2862 LE496
Bore	128 mm
Stroke	157 mm
Fuel	Diesel
Displacement	24.24 l
Power Output	882 kW (1200 hp)
Torque	5000 Nm
Aspiration	Turbocharged
Cooling System	Liquid-cooled
Max. Torque Speed	1, 100 - 1, 500 rpm
