Manhattan 177603 User Manual

4.3 GOOD READ MODE
When active, the scan engine stops the reading session after a successful
decoding. NOTE: This parameter is not used with Continuous and Continuous
+ Flashing modes.
4.4 BUZZER BEEP TONE
4.4.1 BEEP TONE SETUP
9
OPERATING SETTINGS
Low
<Active>
Not Active
<High>
Medium

Manhattan 177603 Specifications

General

Wavelength	650 nm
Sensor type	Laser
Scanner type	2D
Read rate (max)	200 reads/s
Maximum scan width	430 mm
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, Telepen
Optical sensor resolution (W x H)	752 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Cable length	1.5 m
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	435 mA
Power source type	DC
Certification	FCC, CE, UL
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	193 mm
Width	90 mm
Height	72 mm
Weight	135 g
