- TRANSPORT THE LIFT TRUCK ON A PLATFORM
To carry the machine respect the circulation laws.
Ensure that the safety instructions connected to the platform are respected before the loading of the lift truck
and that the driver of the means of transport is informed about the dimensions and the weight of the lift truck
(See chapter : CHARACTERISTICS in paragraph : 2 - DESCRIPTION).
Ensure that the platform has got dimensions and a load capacity sufficient for transporting the lift truck. Check
also the pressure on the contact surface allowable for the platform in connection with the lift truck.
Load the lift truck
- Block the wheels of the platform.
- Fix the loading ramps so that you obtain an angle as little as possible to lift the lift truck.
- Load the lift truck parallel to the platform.
- Stop the lift truck (See chapter : DRIVING INSTRUCTIONS in paragraph : 1 - OPERATING AND SAFETY
INSTRUCTIONS).
Sling the lift truck
- Fix the chocks to the platform at the front and at the back of each tyre “1” (Fig. G4/1) and (Fig. G4/2).
- Stow the lift truck on the platform with enough resisting ropes, at the front of the lift truck, on the fastening
point “1” (Fig. G4/3) and at the rear of the lift truck, on the fastening point “3” (Fig. G4/3).
- Tighten the ropes.
Fig. G4/1
Fig. G4/3
Fig. G4/2
2
2
3
3
11 11
11
MHT 10120 L M
eries
3
34
