MHT 10120 L M
Series
2
2
1
1
-
-
CEILING LIGHT
The switch “A” is incorporated in the light unit.
It has two positions: constant lighting and off.
2
2
2
2
-
-
DOOR LOCK
Outside lock “B” : To open the door, take hold of the handle and
pull it outward.
Two keys for locking the cab are supplied with the truck.
Inside lock “C” : To open the door, take hold of the handle and
pull it inward.
2
2
3
3
-
-
REAR WINDOW OPENING LEVER
To open the rear window, pull the lever "D" clockwise to the right
and push on the window.
2
2
4
4
-
-
UPPER HALF DOOR LOCK
Closed position: To open, push the lock “A” down.
To close, simply pull the handle “B” inward.
Open position : Push the door towards the cab to engage
in the bolt “C” .
To release press the knob “D” or use the lever “E”.
B
C
D
A
D
E
A
B
C
