Manitou MHT10120 - Page 89

B
B
1
1
7
7 - Grease tilting bushes of front axle “1-2” (Fig. B17/1 - B17/2).
Grease tilting bushes of rear axle “3-4” (Fig. B17/3 - B17/4).
B
B
1
1
8
8 - Grease journal and universal the cardan shaft on the rear side “1” (fig. B18/1) and front side “1”
(fig. B18/2-fig. B18/3).
FIG. B17/3 FIG. B17/4
FIG. B17/1 FIG. B17/2
FIG. B18/3FIG. B18/2
FIG. B18/1
1
1
1
1
1
1
1
1
1
1
MHT 10120 L M
Series
