LEGENDE HYDRAULIKANLAGE - ANTRIEB
M = Perkins-Motor 1104D-44 T
P.I.. = Verstellpumpe A4 VG 56DA
R = Hydraulikölbehälter
V.I. = Inch-Ventil
M.I. = Verstellmotor A6 VG 107DA
F.A. = Saugfilter
F.R. = Ablassfilter
KEY TO TRANSMISSION HYDRAULIC SYSTEM
M = 1104D-44 T Perkins engine
P.I. = A4 VG 56DA variable
displacement pump
R = Hydraulic oil tank
V.I. = Inching valve
M.I. = A6 VG 107DA variable
displacement engine
F.A. = Intake filter
F.R. = Drain filter
LEGENDA IMPIANTO IDRAULICO TRASMISSIONE
M = Motore Perkins 1104D-44 T
P.I. = Pompa a cilindrata variabile A4 VG 56DA
R = Serbatoio olio idraulico
V.I. = Valvola inching
M.I. = Motore a cilindrata variabile
A6 VG 107DA
F.A. = Filtro aspirazione
F.R. = Filtro scarico
IT
EN
DE
4
MRT 1440 - 1640-1840
