4-8
TECHNICAL SPECIFICATIONS OF ATTACHMENTS
FLOATING FORK CARRIAGE
TFF 45 MT-1040 TFF 45 MT-1300
PART NUMBER
653344 653345
Rated capacity 4500 kg 4500 kg
Width 1040 mm 1300 mm
Weight 370 kg 400 kg
FLOATING FORK SIDE-SHIFT CARRIAGE
Use is prohibited with the optional single side-shift carriage (TSDL).
TFF 45 MT-1040 DL TFF 45 MT-1300 DL
PART NUMBER
751545 751546
Rated capacity 4500 kg 4500 kg
Side-shift 2x100 mm 2x100 mm
Width 1040 mm 1300 mm
Weight 410 kg 450 kg
FLOATING FORK
PART NUMBER
211922
Section 125x50x1200 mm
Weight 71 kg
