Manitowoc 14000 Product Guide

Performance data
Model 14000
15
Hoist Reeving for Main Load
Block - Single Lead Line
26 mm - No. 76 Main Boom
No. Parts of Line
Maximum Load
kg (lb)
1 14 290 31,500
2 28 580 63,000
3 42 860 94,500
4 57 150 126,000
5 71 440 157,500
6 85 730 189,000
7 100 020 220,500
8 114 310 252,000
9 128 590 283,500
10 142 880 315,000
11 157 170 346,500
12 171 460 378,000
13 185 750 409,500
14 200 030 441,000
Wire Rope Lengths - Single Hoist Line Drum - 26 mm
No. 76 Main Boom
Boom or
Boom and
Jib Length
Whip Line - Drum 1 or 3
(Front or Auxiliary Drum)
Hoist Line - Drum 2
(Rear Drum)
1 Part 2 Part
Total Parts
of Line
m (ft) m (ft) m (ft) m (ft)
20 (66) 58 (190) 82 (270) 335 (1100) 14
23 (76) 64 (210) 91 (300) 366 (1200) 13
29 (95) 76 (250) 110 (360) 373 (1225) 11
35 (115) 88 (290) 128 (420) 411 (1350) 10
41 (135) 101 (330) 146 (480) 434 (1425) 9
47 (154) 113 (370) 165 (540) 450 (1475) 8
53 (174) 125 (410) 183 (600) 450 (1475) 7
59 (194) 137 (450) 201 (660) 450 (1475) 6
65 (213) 149 (490) 219 (720) 450 (1475) 5
71 (233) 162 (530) 238 (780) 450 (1475) 4
77 (253) 174 (570) 256 (840) 450 (1475) 4
83 (272) 186 (610) 274 (900) 450 (1475) 3
89 (292) 198 (650) 293 (960) 450 (1475) 3
95 (312) 210 (690) 311 (1020) — — —
98 (322) 216 (710) — — — — —
NOTE: Hoist and whip line lengths given in table will allow hook to touch ground. When block
travel below ground is required, add additional rope equal to parts of line times added travel
distance. Hoisting distance or line pull may be limited when block travel below ground is
required.
Maximum wire rope length allowed on Drum 3 (Auxiliary Drum) is 235 m (770 ft).
