Specifications
6
Optional: 3,0 m (10'), 6 m (19'), and 12 m (39')
No. 76 boom inserts with steel boom suspension
straps, and FACT™ connection system.
Note: Only one 3,0 m (10') insert is allowed in the
boom configuration.
No. 134 Fixed Jib
Optional: No. 134 basic tubular chord fixed jib 9,1
m (30') in length consisting of 4,6 m (15') jib butt
and 4,6 m (15') jib top with 3,7 m (12') jib strut,
pendants and backstay. Includes RCI hardware.
For use with boom No. 76.
Optional: No. 134 fixed jib inserts 3,0 m (10') and
6,1 m (20') with pendants.
Utilize fixed jib inserts in combination with the No.
134 basic fixed jib for total lengths up to 24,4 m (80').
Note: Jib lengths greater than 18,3 m (60') require the
use of at least one 6,1 m (20') No. 134 fixed jib insert.
No. 135 Luffing Jib
Optional: 21,3 m (70') basic No. 135 tubular
chord luffing jib assembly with RCI hardware
consisting of 8,2 m (27') butt, 6,1 m (20') insert,
and 7,0 m (23') top with two 68,6 cm (27") straight
roller bearing sheaves and pin connected jib
sections, pendants, fixed strut, jib strut, backstay
pendants, boom point wheel, 26 mm luffing jib
hoist line. For use with No. 76 boom.
Optional: 3,0 m (10'), 6,1 m (20'), and 12,2 m (40')
No. 135 inserts with pendants. Utilize luffing jib
inserts in combination with the No. 135 basic
luffing jib for total lengths up to 57,8 m (170').
Note: Only one 3,0 m (10') insert is allowed in the
luffing jib.
Optional Equipment
Optional: Blocks and Hooks –
13,6 mton (15 ton) swivel hook and weight ball.
27,2 mton (30 ton) hook block with one 76,2 cm
(30") sheave for 26 mm wire rope with swivel
hook, hook latch and swivel lock (assembly
block).
54 mton (60 ton) hook block with two 76,2 cm
(30") sheaves for 26 mm wire rope with swivel
hook, hook latch and swivel lock.
91 mton (100 ton) hook block with three 76,2 cm
(30") sheaves for 26 mm wire rope with swivel
hook, hook latch, and swivel lock.
140,6 mton (155 ton) hook block with six 76,2 cm
(30") sheaves for 26 mm wire rope with swivel
hook, hook latch, and swivel lock.
200 mton (220 ton) hook block with seven 76,2
cm (30") sheaves for 26 mm wire rope with
swivel hook, hook latch, and swivel lock.
Optional Hydraulic Test Kit: required to properly
analyze the performance of the EPIC® control
system.
Optional Service Interval Kits: for the regularly
scheduled maintenance of general crane
operations.
Optional Special Paint: in color(s) other than
Manitowoc standard red and black.
Optional Special Customer Decals: custom
vinyl decal(s) of name and/or logo from artwork
supplied by customer.
Optional Export Packaging: basic crane, boom
and jib sections.
Hoist Reeving for Main Load
Block - Single Lead Line
26 mm - No. 76 Main Boom
No. Parts of Line
Maximum Load
kg (lb)
1 14 290 31,500
2 28 580 63,000
3 42 860 94,500
4 57 150 126,000
5 71 440 157,500
6 85 730 189,000
7 100 020 220,500
8 114 310 252,000
9 128 590 283,500
10 142 880 315,000
11 157 170 346,500
12 171 460 378,000
13 185 750 409,500
14 200 030 441,000
