Part Number 80-1505-3 6/11 69
IB0600C/IB0680C/IB0800C/IB1000C
WATER
DISTRIBUTION
TUBE
WATER
CURTAIN
DUMP
VALVE
SHUT OFF
VALVES
ELECTRICAL
COMPARTMENT
ICE/OFF/CLEAN
TOGGLE
SWITCH
ICE
THICKNESS
PROBE
WATER
TROUGH
COOL
VAPOR
VALVE
LIQUID LINE
SOLENOID
VALVE
RECEIVERS
LIQUID
LINE
DRIER
WATER
INLET
VALVE
RECEIVER
SERVICE
VALVE
ELECTRICAL
COMPARTMENT
DISCHARGE
LINE
CHECK
VALVE
