72 Part Number 80-1505-3 6/11
CVD1885/CVD2075/CVD2085/CVD3085
SUCTION
ACCUMULATOR
COMPRESSOR
LIQUID LINE
AND
SUCTION LINE
CONNECTION
POINTS
AIR
CONDENSER
HEAD PRESSURE
CONTROL VALVE
CONDENSER
FAN MOTOR
(CVD3085 HAS 2 FANS)
ACCESS
VALVES
ELECTRICAL
COMP.
CHECK VALVE
ACCESS VALVE
