30 Part Number: 000015431 Rev01 5/19
Dual Evaporator Model
Installation on a Manitowoc Bin
Dual evaporator models will not function correctly with
the stock bin deflector. An ice deflector kit is required for
installation and is ordered separate. Order appropriate kit
(30" or 48") for your bin.
The stock bin deflector must be removed and replaced
with the correct deflector to prevent injury.
n
Warning
PERSONAL INJURY POTENTIAL
Do not operate any ice machine with the deflector
removed.
NOTE: A deflector must be installed on all dual evaporator
models used in bin applications.
2. LOCK IN PLACE WITH PIN
1. SLIDE
FORWARD
