Manitowoc Grove GMK6300L - Page 9

9
Grove GMK6300L
Counterweight
Counterweight

7,0 t
(15,430 lb)

9,5 t
(20,940 lb)

9,5 t
(20,940 lb)

10,0 t
(22,050 lb)

9,0 t
(19,840 lb)
, t , lb X - - - -
, t , lb X X - - -
, t , lb X 2 X - - -
, t , lb X 3 X - - -
, t , lb X 4 X - - -
, t , lb X 4 X X - -
, t , lb X 4 X X 2 X -
, t , lb X 4 X X 2 X 2 X
650 mm
(2.1')
1100 mm
(3.6')
1235 mm
(4.1')
1300 mm
(4.3')
1
2
(4X)
3
4
(2X)
5
(2X)
2990 mm
(9.8')
1790 mm
(5.9')
1790 mm
(5.9')
970 mm
(3.2')
1395 mm
(4.6')
6570 mm
(21.6')
2400 mm
(7.9')
1440mm
(4.7')
1972mm
(6.5')
2420 mm
(7.9')
Center of
gravity
R 3255 mm (10.7')
Tailstwing
R 5500 mm (18.0')
Center turntable
R 4300 mm (14.1')
