Manitowoc National Crane 600E-2

National Crane PUBLISHED 04-26-2019 CONTROL # 113-09 6-15
600E2 OPERATOR MANUAL MAINTENANCE CHECKLIST
6
Crane Operating Speeds
Rotation 375°......................................................................... 35 ± 5 sec (1.8 ± 0.2 rpm) Swing speed based on and
adjustment knob in closed position.
Boom up -10° to 80° .............................................................. 25 ± 5 sec
Boom Down 80° to -10° ......................................................... 20 sec ± 5 sec
Boom Extend/Retract Three Section 16 - 38 ft
Extend (60° elevation) ................................................... 25 ± 5 sec
Retract (60° elevation)................................................... 25 ± 5 sec, 53 fpm (16.1 mpm)
Boom Extend/Retract Three Section 16 - 49 ft
Extend (60° elevation) .................................................. 45 ± 5 sec
Retract (60° elevation)................................................... 75 ± 5 sec
Boom Extend/Retract Three Section 24 - 60 ft
Extend (60° elevation) .................................................. 45 ± 5 sec
Retract (60° elevation)................................................... 40 ± 5 sec
Boom Extend/Retract Three Section 27 - 71 ft
Extend (60° elevation) .................................................. 55 ± 5 sec
Retract (60° elevation)................................................... 50 ± 5 sec
Boom Extend/Retract Four Section 24 - 80 ft
Extend (60° elevation) ................................................... 75 ± 10 sec
Retract (60° elevation)................................................... 125 ± 10 sec
Boom Extend/Retract Four Section 27 - 90 ft
Extend (60° elevation) .................................................. 125 ± 10 sec
Retract (60° elevation)................................................... 105 ± 10 sec
