600E2 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Item Component
1 HCAS Load Range Gauge
2 Boom Up/Down
3Hoist
4 Telescope In/Out
5 Turn Left/Right
6 Emergency Stop Switch
7Horn
8O/R This Side
9 O/R Other Side
10 Stabilizer This Side
11 Stabilizer Other Side
12 Single Front Outrigger
13 HCAS Overload Light
Item Component
14
A2B/Extension Overload
Light
15 Boom Angle Indicator
16 Load Chart
17 Swing Speed Adjustment
18 Level Indicator
19 Front Throttle
20
HCA-ATB Override Key
Switch
21 Boom Length Indicator
22 HCA-ATB Override Button
23 Torsion Box
24 Fuse (10 amp)
25 Outrigger Status Indicator
Item Component
21
15
23
19
18
17
16
1
7
6
12
5
4
3
2
11
8
9
14
22
13
20
2
3
4
5
6
8
9
10
11
12
7
1
10
NOTE: Item 20 is located behind the
access door on the operators
console as shown.
24
FIGURE 3-1
25
25
Fo
r
Reference
Only
