SET-UP NBT40 SERIES OPERATOR MANUAL
Jib in Stow Position
C1
B
A
A
D
Left Side
Right Side
JIb in Operating position
A
D
E
B
C
AStow Pin
B Jib Swing Pin
C Jib Deployment Pins
D Hook Bracket
E Extension Retaining Pin
F Jib Jack
G Jack Handle
H Jib Stowage Bracket
C2
FIGURE 4-1
F
G
E
H
7462-27
7462-28
