Part Number 80-01111-9 7/10 163
Bin Switch Removal — Q170/Q210/Q270
1. Disconnect power to the ice machine at service
disconnect.
2. Disconnect bin switch wires in control box.
3. Insert a small screwdriver through the hole
located in the top of the bin switch, and depress
mounting tab slightly.
4. While depressing mounting tab roll bin switch to
right to release.
5. Pull wiring into evaporator compartment.
Bin Switch Removal
