Manitowoc QM20

200 Part Number 80-01111-9 7/10
High Pressure Cutout (HPCO) Control
Filter-Driers
Drier with dirt-retaining filtration.
Liquid Line Thermistor
QM20/QM30/SM50
10,000 Ohms ± 2% at 25°C (77°F)
Cut-out Cut-in
450 psig ±10
(3103 kPa ±69)
31 bar ±.69
Automatic Reset
Must be below 300 psig
(2068 kPa, 20.68 bar) to reset.
!
Caution
Use only Manitowoc thermistors.
