Single & Twin Evaporator QuietQube® Models
Energized Parts Chart
Ice Making
Sequence of
Operation
Water
Pump
Harvest
Valve(s)
Air
Pumps
Water Inlet
Valve
Water
Dump
Valve
Liquid Line
Solenoid
Valve
Contactor
Refrigeration
Compressor &
Condenser Fan
Motor*
Length of
Time
Start-Up - Initial or After Auto
Shut Off
On Off Off Off On Off Off 45 Seconds
1. Water Purge
2. Refrigeration System
Start-up
Pressure Equalization Off On On Off Off Off Off 5 Seconds
Compressor Start Off On On Off Off On On 5 Seconds
To Next Page
