Manitowoc RFS1200 User Manual

Part Number 000007661 11/16 181
RF0650A
AIRCOOLED
Characteristics vary depending on operating conditions.
ICE PRODUCTION
Model Air Temperature
Water
Temperature
24 hour
Ice Production
RF0650A
70°F/50°F
21°C/10°C
671 lbs
305 kgs
90°F/70°F
32°C/21°C
545 lbs
248 kgs
RFS0650A
70°F/50°F
21°C/10°C
747 lbs
339 kgs
90°F/70°F
32°C/21°C
540 lbs
245kgs
OPERATING PRESSURES PSIG & kPa
Air Temperature
Entering
Condenser
Freeze Cycle
Discharge
Pressure
Suction
Pressure
70°F PSIG
21°C kPa
240-265
1655-1827
33-35
228-241
90°F PSIG
32°C kPa
280-300
1930-2068
34-40
235-276
110°F PSIG
43°C kPa
340-370
2344-2551
40-46
275-318

Manitowoc RFS1200 Specifications

General

Brand	Manitowoc
Model	RFS1200
Category	Ice Maker
Language	English
