RN1000/RN1400 Indicator lights
INDICATOR LIGHT LEGEND
ON OFF ON or OFF FLASHING
• With line voltage supplied the green Power light is on
and the CPU light flashing a heartbeat indicates the
central processing unit is working.
• Yellow lights indicate normal off conditions.
• Red lights indicate an alarm condition.
The sequence below is for normally operating machines.
For alarm conditions refer to troubleshooting which starts
on page 133.
Step 1 Freeze cycle normal light operation
The CPU light flashes and the Refrigeration, Auger on,
Low bin and Power lights are on.
PURGE (Y)
PO
WER (G)
LO
W BIN (G)
AU
GER ON (G)
REFRIG ON (G)
CLEANING (Y)
SERVICE (R)
HI
AMPS (R)
HI PRESS (R)
LO
PRESS (R)
DRAIN CL
OG (R)
TIME DELA
Y (Y)
LO WATER (R)
CPU (G)
HI WATER (R)
