Head Section
Clearances
Top 5” (12.7 cm) is recommended for efficient operation and removal of top
cover/servicing.
Sides 5” (12.7 cm) is recommended for efficient operation and servicing.
There is no minimum clearance required.
Back 3” (7.6 cm) required when routing electrical inlet, water inlet and
refrigeration tubing out of the top of the unit.
5” (12.7 cm) required when routing all connections out the back.
³ The air temperature must be at least 35°F (1.6°C), but must not
exceed 110°F (43.4°C).
³ The location must be free of airborne and other contaminants.
³ The location must not be near heat-generating equipment or in
direct sunlight.
³ The location must not obstruct airflow through or around the ice
machine.
