Manitowoc UDF0140A

126 Part Number 000014797 Rev02 05/18
REFRIGERATION ANALYSIS CHART
Operational Analysis  2  
Ice Production Published 24 hour ice production________________
Calculated (actual) 24 hour ice production_______________
NOTE: The ice machine is operating properly if the ice fill pattern is normal and ice production is within 10%
of charted capacity.
Installation and Water
System
All installation and water related problems must be corrected
before proceeding with chart.
Ice Formation Pattern Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation is normal
-or-
Ice formation is extremely
thin on the bottom of
evaporator
-or-
No ice formation on
evaporator
Ice formation is normal
-or-
No ice formation on entire
evaporator
