38 Part Number 000014797 Rev02 05/18
4. Remove the Water Distribution Tube
• Distribution tube thumbscrews are retained to
prevent loss. Loosen thumbscrews but do not pull
thumbscrews out of distribution tube.
• Loosen the two outer screws and pull forward on
the distribution tube to release.
NOTE: For ease of assembly when reinstalling the water
distribution tube, install the top edge first.
2. PULL DISTRIBUTION TUBE
FORWARD TO REMOVE
To Next Page
