Part Number 000014797 Rev02 05/18 25

Water-cooled Ice Machine

Ice Machine

Voltage Phase

Cycle

Max. Fuse/

Circuit Breaker

Total Amps

U0240

UF0240

115/1/60 15 7.0

208-230/1/60 15 4.0

230/1/50 15 4.0

U0310

UF0310

115/1/60 15 10.0

208-230/1/60 15 4.5

230/1/50 15 4.5

NOTE: Model/serial plate information overrides all data listed in

this chart.

Warning

All wiring must conform to local, state and national

codes.

Warning

The ice machine must be grounded in accordance with

national and local electrical code.
