Mantis compact compostumbler User Manual

3
Parts For The Tumbler Drum
Parts For The Tumbler Drum
PART QUANTITY
ITEM NO. DESCRIPTION NEEDED
1 Drum Panel A 2
2 Drum Panel B 1
3 Endcap 2
4 Tie Rod 3
5 Aerator Base 2
6 Aerator Cap 2
7 Latch Hook 2
8 Latch 2
9 Door 1
10 #10 Bolt 13
11
#10 Flatwashe r25
12
#10 Lockwasher 13
13
#10 Nut 13
14 Acorn Nut 6
15 Wing Nut 2
16
Bolt,
1
/ 4 "x3
1
/ 4 " 2
17
Shoulder Bolt (gold) 12
18 #10 Locknut 12
1
2
3
9
4
78
5
6
10
11
12
13
14
15
16
18
17
