Mantis ElectricTiller - Parts Explosion

16
Electric Tiller
Parts Explosion
P/N 438LA
P/N 438RA
DIRECTION
Raised Hub
Teeth point in
a Clockwise
Direction
DIRECTION
Raised Hub
Teeth point in
a Counter
Clockwise
Direction
When you look at a Tine with the raised hub facing you
and the teeth are pointing in a CLOCKWISE rotation,
you have a LEFT HAND TINE.
When you look at Tine with the raised hub facing you and
the teeth are pointing in a COUNTER CLOCKWISE
rotation, you and a RIGHT HAND TINE.
