Marantz 10 - Page 70

0
Maximum allowable PHONO input level (1 kHz)
MC :
8 mV
MM :
80 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MC) :
76 dB (0.5 mV Input, 1 W Output)
PHONO (MM) :
88 dB (5 mV Input, 1 W Output)
BALANCED 1/BALANCED 2 :
122 dB (4 V Input, Rated output)
LINE 1/LINE 2/RECORDER :
122 dB (2 V Input, Rated output)
0
Tone control
BASS (50 Hz) :
±10 dB
TREBLE (15 kHz) :
±10 dB
0
Operating temperature: 41 °F - 95 °F (5 °C - 35 °C)
0
Power requirement : AC 120 V, 60 Hz
0
Power consumption : 270 W
0
Power consumption in standby mode : 0.1 W
For the purpose of improvement, the specifications and design are subject to change without notice.
