Marantz 3600 - Page 29

REFERENCE
DESIGNATION
MARANTZ
PART NUMBER
434-3912
434-3102
434-5272
434-5122
434-2102
434-3152
434-5102
434-2222
439-2000
434-5431
434-6102
434-4202
433-4102
434-3102
434-5122
434-5392
434-4332
452-2004
452-2005
466-2000
NOMENCLATURE
RESISTOR, C-F 910
RESISTOR, C-F, 100
RESISTOR, C-F, 27K
RESISTOR, C-F, 12K
RESISTOR, C-F, 10
RESISTOR, C-F, 150
NOT USED
NOT USED
NOT USED
RESISTOR, C-F, 10K
RESISTOR, C-F, 22
RESISTOR, C-F, 71.5K + 1%,
1/4W
RESISTOR, C-F, 43K + 2%, 1/4 W
RESISTOR, C-F, 100K
RESISTOR, C-F, 2K
RESISTOR, C-F, 1K + 5%, 1/2 W
RESISTOR, C-F, 100
RESISTOR, C-F, 12K
RESISTOR, C-F, 39K
RESISTOR, C-F, 3.3K
SWITCH, PUSHBUTTON,
6-STATION (SELECTOR)
SWITCH, PUSHBUTTON,
6-STATION (FILTERS)
INTEGRATED CIRCUIT, DUAL
LINEAR OPERATIONAL
AMPLIFIER
NOT USED
REFERENCE MARANTZ
DESIGNATION PART NUMBER
466-2003
466-2003
470-2000
360-1025
360-2005
368-2003
368-2002
562-2000
671-4330
680-4220
741-0610
200-2010-1
360-1029
360-2004
200-2008-1
200-2005-1
359-2002
369-2003
196-2000
195-2000-12
195-2000-52
199-2002
199-2004
NOMENCLATURE
INTEGRATED CIRCUIT, LINEAR
OPERATIONAL AMPLIFIER
INTEGRATED CIRCUIT, LINEAR
OPERATIONAL AMPLIFIER
INTEGRATED CIRCUIT, POWER
SUPPLY REGULATOR
MALE CONNECTOR, F PIN,
-100 SPACING
MALE CONNECTOR, F PIN,
-150 SPACING
SOCKET, I.C., 14-PIN
SOCKET, I.C., 8-PIN
HEAT DISSIPATOR
LOCKWASHER NO. 6, SPT, CD
NUT, HEX, 6-32, CD
SCREW, 6-32 x 3/8 L, PNH.
CRSHD, STL, CD
JACK PANEL ASSEMBLY
PHONO JACK
10-PIN CONNECTOR, .150
SPACING
JACK MOUNTING PANEL,
COMPLETE ASSEMBLY
JACK INPUT PANEL, COM-
PLETE ASSEMBLY
STANDOFF, NO. 8-32 THD
STANDOFF, NO. 6-32 THD x4
PACKING SET:
INSERT, HALF
CARTON INNER
CARTON, OUTER
SERVICE MANUAL
SCHEMATIC DIAGRAM
