• 70% Power Guarantee (in 5
channels)
• Fully discrete wide range ampliers
delivering 7 x 100 W RMS
• Sophisticated new aluminium/
reinforced resin front panel with
hidden front inputs
• Dolby Digital Plus, Dolby TrueHD,
DTS HD Master Audio and 7.1
Multi-channel PCM for High
Denition (HD) Audio from Blu-ray
Disc™
• 32-bit DSP with DD-EX, DTS-ES,
DTS96/24, CSII and DPL IIz
• M-DAX audio enhancer for all
compressed audio formats as MP3,
WMA, AAC, etc
• Sound delay function to sync audio
and video
• 4 x HDMI 1.4 inputs for digital audio
and video including Deep Color
support plus one output
• Room Acoustic Calibration with EQ
by Audyssey for one touch speaker
set-up
• Clear OSD menu structure and ease
of use due to front panel cursor
control
• Pure direct mode for best audio
performance
• 24-bit/192 kHz D/A converters on all
ch annel s
• Multi-zone output
• RS232C, IR Flasher port and DC
trigger for system integration
• Speaker C function for bi-amping of
front channels in 5.1 set-up
• 3D Image Pass Through
• ARC (Audio Return Channel)
• CEC (Consumer Electronic Control)
• HDMI Pass-thru in stand-by
• Input assignment
• USB: Input for iPhone/iPod/HDD/
Flash Drive
• Audyssey Dynamic EQ and Volume
• Discrete level adjustment by input
• Volume limiting & Start-up Volume
setting
Note: Product features highlighted in
blue indicate improvements over
NR1601 model
MAR ANTZ12 AV R EC E IV E R S
MAR ANTZ 13
AV R EC E I V ER S
The new SR6005 is powerful … very powerful – 7 x 110 W RMS to be exact. Combined with high-quality audio
processing this stylish box of tricks creates a devastatingly convincing cinematic experience… and thrusts you right
into the heart of the action. That’s because the digital audio signal – up to Dolby TrueHD and DTS-HD – is fed via
one of the six 3D supporting HDMI 1.4a inputs. In addition, the system’s Dynamic Volume control ensures that the
sound remains the same level even when a commercial interrupts. Also, the video up-scaling of analogue and digital
video signals up to 1080p – by the famous Anchor Bay ABT2015 – avoids the necessity of selecting the right input
on the TV: once it is set-up, the SR6005 automatically makes the right connection. In addition, for ‘new media’ the
SR6005 includes an iPod-digital-compatible USB input behind the front flap, and for Bluetooth devices such as a PC
or mobile phone the receiver is ready with the optional RX101. What’s more, set-up, optimisation and operation are
all quick and easy – with the Audyssey MultEQ and intuitive to use graphic user inter face.
Pure enjoyment has never been easier.
The SR5005 provides 7 x 100 W RMS, has decoders for standard as well as Dolby TrueHD and DTS HD Master
Audio, and comes with four HDMI 1.4a inputs – making it immediately ready for 3D video. It easily handles the most
demanding of scenes in action films, as well as offering excellent-quality music playback, thanks to the advanced
Marantz audio technologies. To ensure you get the best possible audio from compressed files on iPod via USB, the
SR5005 incorporates the M-DAX2 – Marantz Dynamic E xpander version2. This neat lit tle addition also optimises
the quality of MP3 files from either CD or the optional Bluetooth receiver RX101. Everything sounds clearer, more
detailed, and more alive. To finish off, the SR5005 comes with a whole host of convenience features such as ‘auto
set-up’ with Audyssey MultiEQ and Dynamic Volume, multi-room with multi-source flexibility, and ‘video-off’ mode
to ensure you enjoy your movies and music in true dynamic Marantz style. What’s more, all analogue and HDMI
video sources can be up-scaled to 1080p via the Anchor Bay ABT1030 processor.
SR6005 SR5005
3D 7.1 HD AV RECEIVER WITH MULTI-ROOM SOUND 3D 7.1 HD AV RECEIVER WITH MULTI-ROOM SOUND
• Marantz quality discrete 110 W Amp
x 7 ch (8 Ohms, 20 Hz - 20 kHz)
• Support HDMI ver.1.4a 3D, ARC and
Content type, 6 Inputs, 1 Output
• Support HDMI CEC, Deep Color,
x.v.Color, Auto Lip Sync and Standby
Pass Through (Last or selected one
in menu)
• Front USB Audio input for iPod/
iPhone digital connection or USB
Memory
• Dolby TrueHD, Digital Plus, Prologic
IIz, IIx, II, Virtual Speaker,
Headphone
• DTS-HD Master Audio, High
Resolution Audio, ES Discete 6.1,
Matrix6.1, Neo:6, 96/24, Express,
Neural Surround
• Audyssey Dynamic Volume and
Dynamic EQ
• Audyssey MultEQ Auto Calibration
• Bluetooth Wireless Audio
Transmission Capability with option
RX101
• Composite/Component to HDMI
scaling up to 1080p
• HDMI to HDMI scaling
• Composite to Component Analogue
up conversion
• OSD overlay on HDMI output
• Assignable HDMI, Component
inputs
• Anchor Bay 10-bit Video
Processing/Scaling
• M-DAX 2 (Improved Algorithm,
Marantz Dynamic Audio eXpander
ver.2)
• New color GUI On Screen Display
• Dot Matrix x 2 lines rich info.
display
• Clean front door design
• Input Rename, Skip, Level control
• Selectable various volume setup:
Power on, Limit and Mute level
• 9 pair screw type speaker terminals
• Zone2 Audio Pre outputs
• 7.1 ch Inputs
• 7.1 ch Pre out + second Subwoofer
Pre out
• RS-232C for Custom Installation
• IR Flasher In
• DC Trigger Out
• Marantz D-Bus(RC-5) In/Out
• External IR Receiver Capability with
option RX101
• Detachable Power Code (IEC320 2
pin type)
• Backlight, LCD, Learning and
Pre-code System Remote Controller
Note: Product features highlighted in
blue indicate improvements over
SR5005 model
