Pre-out for Bi-Amp / Pre-out for Front B
When “Assign Mode” is set to “9.1ch (Bi-Amp)” or “9.1ch + Front B” in
the menu, select the PRE OUT connectors used for bi-amp or second
pair front speakers.
HEIGHT 2
(Default)：
The assigned channels are output from
the HEIGHT2 PRE OUT connectors. Up
to one pair of height, ceiling, and Dolby
Atmos Enabled channels can be used.
SURROUND BACK:
The assigned channels are output from
the SURROUND BACK PRE OUT
connectors. The surround back channel
cannot be used.
o
Floor
Select the floor speakers location.
5ch & SB
(Default):
This layout combines a surround back
speaker with the basic 5-channel layout.
5ch:
This is a basic 5-channel layout that uses
front speakers, center speakers and
surround speakers.
