Speaker configuration and “Amp Assign” settings
This system configuration plays back 11-channels. You can create speaker systems such as a bi-amp connection by changing the “Amp Assign” settings.
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 216)
Playback speaker in MAIN ZONE “Amp Assign” settings Connection page
5.1-channel playback 11.1ch (Default) 51
7.1-channel playback 11.1ch (Default) 52
9.1-channel playback 11.1ch (Default) 56
11.1-channel playback 11.1ch (Default) 63
9.1-channel playback (bi-amp connection of front speakers) 9.1ch (Bi-Amp) 69
9.1-channel playback + second pair of front speakers 9.1ch + Front B 70
The sound mode that can be selected varies according to the speaker configuration.
The following pages provide basic connection examples.
