Marantz CD4000/N2B - Electrical Partslist AF Board; AF Board Capacitors; AF Board Resistors

10-5
MISCELLANEOUS
1255 4822 071 56301 FUSE T 630mA/250V
1256 4822 071 56301 FUSE T 630mA/250V
1503 4822 267 31729 CINCH SOCKET
1504 4822 265 20553 CINCH SOCKET
CAPACITORS
2250 4822 124 41407 0,47 F 20% 63V
2251 4822 124 11769 220 F 20% 50V
2252 4822 126 11585 22nF 20% 50V
2253 4822 126 11585 22nF 20% 50V
2254 4822 124 11878 4700 F 20% 16V
2255 4822 126 12882 100nF 20% 50V
2256 4822 126 11585 22nF 20% 50V
2257 4822 126 11585 22nF 20% 50V
2258 4822 124 40784 3300 F 20% 16V
2259 4822 124 80144 220 F 20% 25V
2500 4822 126 11585 22nF 20% 50V
2502 4822 124 80144 220 F 20% 25V
2509 4822 122 10466 220pF 10% 50V
2510 4822 122 10466 220pF 10% 50V
2511 4822 124 40433 47 F 20% 25V
2512 4822 124 40433 47 F 20% 25V
2513 4822 122 33519 470pF 10% 50V
2514 4822 122 33519 470pF 10% 50V
2521 4822 124 22263 220 F 20% 25V
2522 4822 124 22263 220 F 20% 25V
2523 4822 121 51387 10nF 20% 16V
2524 4822 124 40433 47 F 20% 25V
2529 4822 122 33197 1nF 10% 50V
2530 4822 122 33197 1nF 10% 50V
2531 4822 126 11585 22nF 20% 50V
2541 4822 124 21913 1 F 20% 63V
2543 4822 126 12882 100nF 20% 50V
RESISTORS
3251 4822 053 10471 470 5% 1W
3252 4822 053 10471 470 5% 1W
3253 4822 116 52257 22k 5% 0,5W
3254 4822 116 52283 4,7k 5% 0,5W
3255 4822 116 52256 2,2k 5% 0,16W
3256 4822 050 11002 1k 5% 0,2W
3257 4822 116 52283 4,7k 5% 0,5W
3258 4822 116 52283 4,7k 5% 0,5W
3259 4822 052 10478 4,7 5% NFR
3260 4822 052 10568 5,6 5% 0,33W
3500 4822 116 52289 5,6k 5% 0,16W
3501 4822 050 21003 10k 1% 0,6W
3502 4822 116 52175 100 5% 0,5W
3503 4822 116 52175 100 5% 0,5W
3504 4822 116 52175 100 5% 0,5W
3505 4822 116 52175 100 5% 0,5W
3506 4822 116 52244 15k 5% 0,5W
3507 4822 050 21003 10k 1% 0,6W
3511 4822 116 52269 3,3k 5% 0,5W
3512 4822 116 52269 3,3k 5% 0,5W
RESISTORS
3513 4822 116 83884 47k 5% 0,16W
3514 4822 116 83884 47k 5% 0,16W
3527 4822 116 52256 2,2k 5% 0,16W
3532 4822 116 83874 220k 5% 0,5W
3534 4822 050 21003 10k 1% 0,6W
3535 4822 116 52289 5,6k 5% 0,16W
3537 4822 116 83872 220 5% 0,5W
3538 4822 116 52207 1,2k 5% 0,5W
3539 4822 050 11002 1k 5% 0,2W
3540 4822 050 11002 1k 5% 0,2W
3541 4822 050 11002 1k 5% 0,2W
3542 4822 050 11002 1k 5% 0,2W
3543 4822 050 11002 1k 5% 0,2W
3544 4822 050 11002 1k 5% 0,2W
3545 4822 050 11002 1k 5% 0,2W
3547 4822 050 11002 1k 5% 0,2W
3548 4822 116 52256 2,2k 5% 0,16W
3556 4822 116 52176 10 5% 0,5W
3557 4822 052 10688 6,8 5% 0,33W
DIODES
6250 4822 130 34379 BZX79-C27
COILS
5801 4822 156 31058 100 H
6251 4822 130 34174 BZX79-B4V7
6252 4822 130 31878 1N4003G
6253 4822 130 31878 1N4003G
6254 4822 130 31878 1N4003G
6255 4822 130 31878 1N4003G
6256 4822 130 31878 1N4003G
6257 4822 130 31878 1N4003G
6258 4822 130 31878 1N4003G
6259 4822 130 31981 BZX79-C3V9
6260 4822 130 31878 1N4003G
6500 4822 130 30621 1N4148
TRANSISTORS
7250 4822 130 41327 BC327-40
7252 5322 130 60068 BC558C
7500 4822 130 41327 BC327-40
7501 5322 130 60068 BC558C
7504 4822 130 44568 BC557B
7507 4822 130 41344 BC337-40
7508 4822 130 41344 BC337-40
7509 4822 130 41344 BC337-40
7510 4822 130 41344 BC337-40
INTEGRATED CIRCUITS
7251 4822 209 80817 L7805CV
7502 4822 209 31147 TDA1545A/N2 DAC
7505 4822 209 83274 NJM4560D
ELECTRICAL PARTSLIST AF BOARD
