2-1
General
Dimensions (WxHxD) : 435 x 86 x 265mm
Weight : 2,9kg
Accessories
Instruction for use : 3139 116 18890 for /N
: 3139 116 19100 for /K
Remote control : 3139 228 82590
Mains voltage
/N : 220-230V( 10%) 50Hz
/K :110-120V/220-230V( 10%) 50/60Hz
Power consumption
stand by : 5W
operating : approx. 8W
Audio performance
Number of channels : 2
Output voltage (Line out) : 2V
RMS
3dB
Unbalance left-right : 1dB
Frequency response : 20Hz-20kHz 0,4dB
Signal to noise ratio : 98 dB typ.
Dynamic range : 95dB typ. at 1kHz
THD : 0,0063% at 1kHz
Channel separation : 85dB typ. at 1kHz
Headphone output
Output level (1kHz, 0dB) : 5V
RMS
Unbalance left-right : 1,2dB
Output impedance : 120
Load impedance : 32 - 600
Output power : 25mW at 32
: 52mW at 120
: 29mW at 600
Laser
Output power : <5mW (3mW typ.)
Wavelength : 780nm
Measurement setup
Use Audio Signal disc SBC429 4822 397 30184
