NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
34
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
NOT STANDARD SPARE PARTS
17 BLACK nsp 24AW257010 CABINET, TOP CKC1A140K117
17 GOLD nsp 24AW257110 CABINET, TOP CKC1A140K118
nsp 24AW801010 BOX, OUT CARTON CPG1A725Z
nsp nsp CORD, PIN CJS4N014Z
nsp nsp CORD, PIN BLACK (1M) CJS4M027Z
nsp 24AW809010 PAD, SNOW CPS1A624
CD MECHANISM (LOADER ASS'Y)
1 24AW163010 24AW163010 TRAY (C) 9A07979600
2 nsp nsp
3 nsp nsp GEAR COVER (S) 9A07979700
4 24AW058010 24AW058010 TRAY GEAR (S) 9A07268500
5 24AW104010 24AW104010 CHUCKING PLATE 9A07268900
6 nsp nsp SCREW +PTPWH 2.6X7 9A07269900
7 nsp nsp YOKE (S) , CHUCKING 9A06965300
8 nsp nsp MAGNET 9A06965400
9 24AW056010 24AW056010 DAMPER 9A07268700
10 24AW005010 24AW005010 CHUCKING PULLEY 9A07979800
11 nsp nsp SUB CHASSIS 2130 9A07979900
12 nsp nsp COIL SPRING (FRONT) 9A07980000
13 nsp nsp COIL SPRING (BACK) 9A07980100
14 nsp nsp WASHER 2130 9A07980200
15 nsp nsp SCREW+P2.6X10 9A07980300
16 24AW259010 24AW259010 INSULATOR 9A07980400
17 24AW304010 24AW304010 MD ASS'Y (KSS-213CCM) MECHA TRAVERSE 9A07980500
18 nsp nsp OUTSERT MAIN CHASSIS(S) 9A07980600
19 nsp nsp SCREW+PTPWH2.6X16 9A06966200
20 24AW058020 24AW058020 DRIVE GEAR (S) 9A07980700
21 24AW054010 24AW054010 CONTROL CAM (S) 9A07269000
22 24AW116010 24AW116010 LEAF SW 9A07268000
23 nsp nsp PIN, CONNECTOR 5P 9A06966600
24 nsp nsp PC BOARD, LOADING 9A06966700
25 24AW127010 24AW127010 MOTOR ASSY LOADING 9A06966800
26 24AW058030 24AW058030 MIDWAY GEAR (S) 9A07980800
27 24AW262010 24AW262010 LOADING PULLEY 9A07268600
28 24AW264010 24AW264010 LM BELT 9A07980900
29 nsp nsp SCREW+B2.6X2.5 9A06967200
