Marantz CDR631 Service Manual

48
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
S815 9965 000 05921 PUSH SWITCH
ESB92S94B TV-5 1.5MM
SP01012480
P916-HEAD PHONE
CIRCUIT BOARD
P916-CAPACITORS
C901
4822 124 23052 ELECT 100µF 16V RC-2 EJ10701610
C906
C907 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C908 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C909 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C910 4822 126 12339 CER. CHIP 2200pF DK96222300
P916-RESISTORS
RN01 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
RN02 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R903 4822 051 30153 CHIP 15k
Ω ±5% 1/16W NN05153610
R904 4822 051 30153 CHIP 15k
Ω ±5% 1/16W NN05153610
R905 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R906 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R907 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R908 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R909 4822 051 30151 CHIP 150
Ω ±5% 1/16W NN05151610
R910 4822 051 30151 CHIP 150
Ω ±5% 1/16W NN05151610
R911 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R912 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R920 9965 000 00602 VAR. 10k
Ω B
RK09L12B0 D-CUT REVERSE
RM01031170
P9164-SEMICONDUCTORS
QN01 4822 130 63601 CHIP TRS. 2SC4213 HX342132A0
QN02 4822 130 63601 CHIP TRS. 2SC4213 HX342132A0
Q901 4822 209 31378 IC NJM4556MB HC10045090
P916-MISCELLANEOUS
J901 FB 4822 267 31126 JACK HLJ1520-01-3410 YJ01003020
J901 N1M 4822 267 31126 JACK HLJ1520-01-3410 YJ01003020
J901 U1B 4822 267 31126 JACK HLJ1520-01-3410 YJ01003020
L901
9965 000 05005 FERRITE BEADS FC90020120
L903 BK1608HM102-T
PP16-MAIN CIRCUIT BOARD
PP16-CAPACITORS
CA01 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CA02 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CA03 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CA04 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CA05 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CA06 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CA07 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CA08 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CA11 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CA12 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB01 4822 126 11568 CER. CHIP 470pF DK96471300
CB02 4822 126 11568 CER. CHIP 470pF DK96471300
CB11 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CB12 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CC01 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CC02 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CF52 4822 126 11568 CER. CHIP 470pF DK96471300
CM01
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CM08
CM09 4822 124 41539 ELECT. 47µF 16V OA47601620
CM10 4822 124 41539 ELECT. 47µF 16V OA47601620
CM11 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
CM21 4822 124 41539 ELECT. 47µF 16V OA47601620
CM22 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CT01 4822 126 12339 CER. CHIP 2200pF DK96222300
CT02 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CT03 4822 122 33777 CER. CHIP 47pF ±5% 50V DD95470300
CT04 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CT05 4822 122 31765 CER. CHIP 100pF ±5% 50V DD95101300
CT11 4822 126 12339 CER. CHIP 2200pF DK96222300
CT12 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CT13 4822 122 33777 CER. CHIP 47pF ±0.5pF 50V DD95470300
CT14 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CT15 4822 122 31765 CER. CHIP 100pF ±5% 50V DD95101300
CT31 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CT32 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C301 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C314 4822 122 33777 CER. CHIP 47pF ±5% 50V DD95470300
C326 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C327 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C328 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C336 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C337 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C338 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C601 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C602 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C603 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C604 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C606 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C607 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C608 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C609 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C615 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C616 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C621 4822 126 11568 CER. CHIP 470pF DK96471300
C622 4822 126 11568 CER. CHIP 470pF DK96471300
C623
4822 126 14124 MICA CHIP 220pF J DF95221040
C626 ECHU1H221JB5
C627 4822 126 11568 CER. CHIP 470pF DK96471300
C628 4822 126 11568 CER. CHIP 470pF DK96471300
C639 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C640 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C641
4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C644
C651 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C652 4822 122 31765 CER. CHIP 100pF ±5% 50V DD95101300
C661 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C662 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C663 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C664 4822 126 11687 CER. CHIP F104Z16 0.1µF DK98104200
C671 4822 122 31765 CER. CHIP 100pF ±5% 50V DD95101300
C672 4822 126 11568 CER. CHIP 470pF DK96471300
C680 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C688 4822 126 12339 CER. CHIP 2200pF DK96222300
C690
4822 126 12339 CER. CHIP 2200pF DK96222300
C698
C699 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C701 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C702 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C703 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C704 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C707 4822 126 11568 CER. CHIP 470pF DK96471300
C708 4822 126 11568 CER. CHIP 470pF DK96471300
C711 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C712 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C713
4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C716
