Marantz CDR631 Service Manual

49
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C717 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C718 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C720 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C721 4822 124 41539 ELECT. 47µF 16V OA47601620
C722 4822 124 41539 ELECT. 47µF 16V OA47601620
C723
4822 122 31765 CER. CHIP 100pF ±5% 50V DD95101300
C728
C729 4822 126 13344 MICA CHIP 1500pF J DF95152040
C730 4822 126 13344 MICA CHIP 1500pF J DF95152040
C741
4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C754
C777
4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C780
C781
4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
C788
C791
4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C798
PP16-RESISTORS
RA01 4822 051 30479 CHIP 47
Ω ±5% 1/16W NN05470610
RB01
4822 051 30102 CHIP 1k Ω ±5% 1/16W NN05102610
RB04
RF51 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RF57 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RM01 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
RM02 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
RM03
4822 051 30681 CHIP 680 Ω ±5% 1/16W NN05681610
RM06
RM07 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RM08 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RM09 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
RM10 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
RM11 4822 116 83819 CHIP 18k
Ω ±5% 1/16W NN05183610
RM12 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RM13 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
RM14 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RM21 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
RM22 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RM24 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
RN51
4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
RN54
RT02 4822 051 30759 CHIP 75
Ω ±5% 1/16W NN05750610
RT03 4822 117 12139 CHIP 22
Ω ±5% 1/16W NN05220610
RT12 4822 051 30759 CHIP 75
Ω ±5% 1/16W NN05750610
RT13 4822 117 12139 CHIP 22
Ω ±5% 1/16W NN05220610
RT31 FB 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RT32 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
RT33 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R301 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R311 4822 051 30759 CHIP 75
Ω ±5% 1/16W NN05750610
R326 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R327 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R328
4822 117 13632 CHIP 100k Ω ±5% 1/16W NN05104610
R331
R336 4822 051 30682 CHIP 6.8k
Ω ±5% 1/16W NN05682610
R337 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R338 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R339 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R340 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R341 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R621
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R630
R631
4822 051 30102 CHIP 1k Ω ±5% 1/16W NN05102610
R634
R635
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R638
R651
4822 051 30101 CHIP 100 Ω ±5% 1/16W NN05101610
R654
R655 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R656 4822 051 30223 CHIP 22k
Ω ±5% 1/16W NN05223610
R657 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R658 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R661 4822 051 30221 CHIP 220
Ω ±5% 1/16W NN05221610
R662
4822 051 30479 CHIP 47 Ω ±5% 1/16W NN05470610
R667
R671 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R672 4822 051 30221 CHIP 220
Ω ±5% 1/16W NN05221610
R673 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R674 4822 051 30221 CHIP 220
Ω ±5% 1/16W NN05221610
R675 4822 051 30479 CHIP 47
Ω ±5% 1/16W NN05470610
R676 4822 051 30479 CHIP 47
Ω ±5% 1/16W NN05470610
R678 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R679 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R680 4822 051 30479 CHIP 47
Ω ±5% 1/16W NN05470610
R681 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R682 4822 051 30479 CHIP 47
Ω ±5% 1/16W NN05470610
R685 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R686 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R687 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R691 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R701 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R702 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R703
4822 051 30102 CHIP 1k Ω ±5% 1/16W NN05102610
R706
R707 4822 051 30222 CHIP 2.2k
Ω ±1/16W NN05222610
R708 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R709 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R710 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
R711 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
R712 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
R713 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R714 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R715
4822 051 30223 CHIP 22k Ω ±5% 1/16W NN05223610
R718
R719 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R720 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R721 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R722 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
R723 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R724 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R725
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R730
R731 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R732 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R733
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R736
R737 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R738 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R739
4822 051 30331 CHIP 330 Ω ±5% 1/16W NN05331610
R742
