Marantz CDR631 Service Manual

50
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R743 4822 051 30102 CHIP 1k Ω ±5% 1/16W NN05102610
R744 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R745 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R746 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
R747 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
R748 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
R749 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R750 4822 051 30222 CHIP 2.2k
Ω ±5% 1/16W NN05222610
R751
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R758
R775
4822 051 30333 CHIP 33k Ω ±5% 1/16W NN05333610
R778
R779 9965 000 07426 VAR. 50k
Ω C RK09K111 RK05030950
R780 9965 000 07426 VAR. 50k
Ω C RK09K111 RK05030950
R781 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R782 4822 051 30102 CHIP 1k
Ω ±5% 1/16W NN05102610
R783 4822 051 30471 CHIP 470
Ω ±5% 1/16W NN05471610
R784 4822 051 30471 CHIP 470
Ω ±5% 1/16W NN05471610
R785
4822 117 13632 CHIP 100k Ω ±5% 1/16W NN05104610
R788
R789
4822 051 30102 CHIP 1k Ω ±5% 1/16W NN05102610
R792
R793
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
R796
SF51 4822 277 21559 SLIDE SWITCH SLIDE SWITCH
INT/EXT
SS02021150
PP16-SEMICONDUCTORS
DF51 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DM01 4822 130 81169 CHIP DIODE 02CZ5.6Y HZ30006050
DM21 4822 130 81169 CHIP DIODE 02CZ5.6Y HZ30006050
D661 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D701
4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D706
QA01 9965 000 05885 IC AK5351VF
20BIT A/D CONVERTER
HC10023480
QA02 4822 209 71373 IC NJM78L05A HC38105090
QC01 4822 209 17437 IC PQ09RF1 HC31909320
QF51 4822 130 42593 DIG.TRS.
DTA124EU RN2303 UMT
BA12303000
QF52 4822 130 61553 DIG.TRS.
DTC124EU RN1303 UMT
BA21303000
QM01 4822 130 62548 TRS. 2SB1185 E.F HT211852B0
QM02 4822 130 62549 TRS. 2SD1762 E.F HT417622B0
QM03 4822 209 71451 IC NJM4558M HC10011090
QM04 4822 130 61553 DIG.TRS.
DTC124EU RN1303 UMT
BA21303000
QM06 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QM07 4822 130 61554 CHIP TRS. 2SA1586 Y G HX115862B0
QM21
4822 130 61553 DIG.TRS. BA21303000
QM24 DTA124EU RN2303 UMT
QN51
4822 130 63601 CHIP TRS. 2SC4213 HX342132A0
QN54
QT31 4822 209 31568 IC CMOS 74HCU04 FLAT HC700400Z0
QY45 4822 130 61553 DIG.TRS.
DTC124EU RN1303 UMT
BA21303000
Q326 5322 209 60472 IC SN75157PS HC10070370
Q331 4822 209 31568 IC CMOS 74HCU04 FLAT HC700400Z0
Q332 4822 209 30426 IC CMOS 74HC00 FLAT HC700000Z0
Q601 9965 000 07427 IC AK4393 DA CONVERTER HC10027480
Q603 4822 209 17155 IC NJM2068MY HC10102090
Q604 4822 209 17155 IC NJM2068MY HC10102090
Q615 4822 209 71373 IC NJM78L05A HC38105090
Q661 9965 000 05912 IC 74HCT244AF HC724400Q0
Q662 4822 209 91012 IC TC74HCT04AF HC700405Q0
Q663 4822 209 12416 IC 74HC4066 AF HC706600Z0
Q664 4822 209 61494 IC 74HC74 FLAT HC707400Z0
Q665 4822 130 61553 DIG.TRS.
DTC124EU RN1303 UMT
BA21303000
Q666 4822 130 42593 DIG.TRS.
DTA124EU RN2303 UMT
BA12303000
Q701 4822 209 83804 IC LC4966 HC10150030
Q702 9965 000 05884 IC DS1807 DIP HC10100990
Q703 4822 209 71451 IC NJM4558M HC10011090
Q704 4822 209 71451 IC NJM4558M HC10011090
Q705 9965 000 05910 IC NJM2082M HC10103090
Q706 9965 000 05910 IC NJM2082M HC10103090
Q707 4822 209 71451 IC NJM4558M HC10011090
Q708 4822 209 71451 IC NJM4558M HC10011090
Q761
4822 209 71451 IC NJM4558M HC10011090
Q764
PP16-MISCELLANEOUS
JF51 9965 000 07431 TERMINAL 14X16 RCA 2L2P
ORG NI FRONT-GND
YT02021090
JT01 9965 000 07432 TERMINAL 14X14 RCA 2L2P
BLK NI FRONT-GND
YT02021220
J301 4822 218 11487 OPTICAL RECIVER GP1F32R YJ15000150
J311 4822 265 10684 TERMINAL YKC21-3639 YT02011020
J601 996500005911 JACK 30FLT-SM1-TB YJ07021230
J651 4822 267 31727 TERMINAL 14X14 RCA 2L2P
W/R NI FRONT-GND
YT02021210
J701 4822 267 31727 TERMINAL 14X14 RCA 2L2P
W/R NI FRONT-GND
YT02021210
LA01 4822 157 63234 CHIP INDUCTANCE
NL322522-4R7M
LU12472010
LF51 9965 000 05005 FERRITE BEADS
BK1608HM102-T
FC90020120
LT03 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LT13 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
L615 4822 157 63234 CHIP INDUCTANCE
NL322522-4R7M
LU12472010
L651 9965 000 05005 FERRIT BEADSBK1608HM102-
T
FC90020120
L652 9965 000 05005 FERRIT BEADSBK1608HM102-
T
FC90020120
L701 9965 000 05005 FERRITE CORE
BK1608HM102-T
FC90020120
L702 9965 000 05005 FERRITE CORE
BK1608HM102-T
FC90020120
L711 4822 157 63234 CHIP INDUCTANCE
NL322522-4R7M
LU12472010
S321 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150
S701 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150
PP26-XLR CIRCUIT BOARD
PP26-CAPACITORS
CT21 FB 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C323 4822 122 33777 CER. CHIP 47pF ±5% 50V DD95470300
C324 4822 122 33777 CER. CHIP 47pF ±5% 50V DD95470300
C761
4822 122 33777 CER. CHIP 47pF ±5% 50V DD95470300
C770
