Marantz CDR631 Service Manual

51
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PP26-RESISTORS
R321 4822 051 30331 CHIP 330
Ω ±5% 1/16W NN05331610
R322 4822 051 30331 CHIP 330
Ω ±5% 1/16W NN05331610
R323 4822 051 30331 CHIP 330
Ω ±5% 1/16W NN05331610
R761
4822 117 13632 CHIP 100k Ω ±5% 1/16W NN05104610
R764
PP26-MISCELLANEOUS
JT21 FB 4822 267 31369 OPT. CONNECTOR GP1F32T
OPTICAL OUTPUT
YJ15000090
J321 9965 000 02540 JACK NC3FAH2
4P CANON HOLZ
YJ01004340
J761 9965 000 02540 JACK NC3FAH2
4P CANON HOLZ
YJ01004340
J762 9965 000 02540 JACK NC3FAH2
4P CANON HOLZ
YJ01004340
L751
9965 000 05005 FERRITE CORE FC90020120
L754 BK1608HM102-T
PY16-FTD CIRCUIT BOARD
PY16-CAPACITORS
CY03 4822 126 11704 CER. CHIP 0.022uF DK98223300
CY04 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
CY05 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
CY06 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY08 4822 126 11704 CER. CHIP 0.022uF DK98223300
CY09 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
CY10 4822 122 31765 CER. CHIP 100pF ±5%G 50V DD95101300
CY13 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY14 4822 124 11432 TANTL.CHIP 100µF 10V EY10701020
CY41 4822 124 41842 TANTL.CHIP 47µF 16V EY47601620
PY16-RESISTORS
RY01 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY02 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY03 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY06 4822 051 30471 CHIP 470
Ω ±5% 1/16W NN05471610
RY09 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RY10 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RY11 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
RY12 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RY13 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RY14 4822 051 30332 CHIP 3.3k
Ω ±5% 1/16W NN05332610
RY15 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY16 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY17 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY21
4822 051 30682 CHIP 6.8k Ω ±5% 1/16W NN05682610
RY26
RY44 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RY46 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
PY16-SEMICONDUCTORS
DY04 9965 000 04970 CHIP ZENER DIODE
02CZ3.3X 3.3V
HZ30014050
DY41 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DY42 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
QY01 9965 000 07429 MICROPROCESSOR
TMP87CH74F
HU385KT00F
QY02 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QY03 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QY04 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QY41 4822 130 42593 DIG.TRS. DTA124EU RN2303 BA12303000
QY42 4822 130 61553 DIG.TRS. DTC124EU RN1303 BA21303000
QY43 4822 130 61553 DIG.TRS. DTC124EU RN1303 BA21303000
QY44 4822 130 42593 DIG.TRS. DTA124EU RN2303 BA12303000
PY16-MISCELLANEOUS
LY01 482215753873 CHIP INDUCTANCE
NL322522-101K
LU12104010
VY01 9965 000 05916 DISPLAY UNIT FTD
BJ727GNK 15GRID X 22ANO.
HQ31208410
XY01 9965 000 07430 SERAMIC VIB.
CSTCC8.00MG-TC 8.000MHz
FQ08004070
PY26-SWITCH
CIRCUIT BOARD
PY26-CAPACITOR
CY21 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
PY26-RESISTORS
RY27 4822 116 82487 CHIP 0
Ω NN05000610
RY28 4822 116 82487 CHIP 0
Ω NN05000610
PY26-MISCELLANEOUS
SY04 9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY08 9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY10 9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY12 9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY13 9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY51
9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY60
PY36- IR CIRCUIT BOARD
CY07 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
RY04 4822 051 30101 CHIP 100
Ω ±5% 1/6W NN05101610
ZY01 9965 000 06833 PHOTO UNIT
IR SENSOR RPM6936-H4
HW10008210
PY46- JOG CIRCUIT BOARD
SY26 9965 000 05915 ROTARY SWITCH EC11B ROT.
ENCODER WITH PUSH. SW
SR03030030
PY56- STANDBY LED
CIRCUIT BOARD
DY01 4822 130 11569 L.E.D. HLMF-K200 #2UL RED HI10005340
