Marantz DV7010 - Page 39

1-51
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
DP01
DP04
9965 000 04986 CHIP DIODE
U1BC44 1A/100V
HZ20032050
DP05
DP08
9965 000 04986 CHIP DIODE
U1BC44 1A/100V
HZ20032050
DP09 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP10 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP11 9965 000 07632 CHIP DIODE ZENER
MA8056-L 5.6V
HZ30007020
DP12 4822 130 81248 DIODE S1WB(A)60 30A
600V
HD20031290
DP13 4822 130 81244 DIODE ERA22-10 HD20008130
DP14 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP15
17 18A /L,/U 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP15
7010 /F,/L,/U 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP16
17 18A /L,/U 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP16
7010 /F,/L,/U 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP19 4822 130 82019 CHIP DIODE SBD
SFPL-52 200V 0.9A
HZ20002080
DP20 4822 130 82019 CHIP DIODE SBD
SFPL-52 200V 0.9A
HZ20002080
DP21 9965 000 07633 DIODE SBD RK33 30V 2.5A HD20052080
DP22 9965 000 07634 DIODE SBD EK19 90V 1.5A HD20053080
DP23 4822 130 11074 DIODE SBD RK46 60V 3.5A HD20050080
DP24 4822 130 82019 CHIP DIODE SBD
SFPL-52 200V 0.9A
HZ20002080
DP25 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DP26 9965 000 04986 CHIP DIODE
U1BC44 1A/100V
HZ20032050
DP27 9965 000 07632 CHIP DIODE ZENER
MA8056-L 5.6V
HZ30007020
DP28 9965 000 03119 CHIP DIODE ZENER
MA8033-H 3.3V
HZ30012020
DP29 9965 000 04986 CHIP DIODE
U1BC44 1A/100V
HZ20032050
DS01 9965 000 07629 CHIP DIODE MA8039-H HZ30025020
DS02 9965 000 07640 CHIP DIODE UDZ TE-17 10B HZ30009210
DS03 9965 000 07640 CHIP DIODE UDZ TE-17 10B HZ30009210
DS04
DS07
4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DV01
17 /N 7010 /N 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
QC01
17 /F,/S 18A IC 74HC4053 HC705300Z0
QC01
7010 /A,/C,/F
/L,/S,/U
IC 74HC4053 HC705300Z0
QC02
17 /F,/S 18A IC LA7213 HC10270030
QC02
7010 /A,/C,/F
/L,/S,/U
IC LA7213 HC10270030
QC03
17 /F,/S 18A 9965 000 07641 IC TK15420M HC10035420
QC03
7010 /A,/C,/F
/L,/S,/U
9965 000 07641 IC TK15420M HC10035420
QC04
17 /F,/S 18A 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QC04
7010 /A,/C,/F
/L,/S,/U
4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QC05
17 /F,/S 18A 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC05
7010 /A,/C,/F
/L,/S,/U
4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC06
17 /F,/S 18A 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC06
7010 /A,/C,/F
/L,/S,/U
4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC07
17 /F,/S 18A 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC07
7010 /A,/C,/F
/L,/S,/U
4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC08
17 /F,/S 18A 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QC08
7010 /A,/C,/F
/L,/S,/U
4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QC09
17 /F,/S 18A 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC09
7010 /A,/C,/F
/L,/S,/U
4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC10
17 /F,/S 18A 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC10
7010 /A,/C,/F
/L,/S,/U
4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC11
17 /F,/S 18A 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC11
7010 /A,/C,/F
/L,/S,/U
4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QC12
17 /F,/S 18A 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC12
7010 /A,/C,/F
/L,/S,/U
4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QC13
17 /F,/S 18A 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QC13
7010 /A,/C,/F
/L,/S,/U
4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QD01 9965 000 04649 IC PCM1735 HC10014610
QD02 9965 000 01338 IC TC7SET04F HC007205K0
QD03 4822 209 90685 IC TC7SH04FU HC007705K0
QH01 4822 130 42839 FET 2SK369 BL
VDGS-40V PDO.4W
HF203691B0
QH02 4822 130 42839 FET 2SK369 BL
VDGS-40V PDO.4W
HF203691B0
QH03 4822 130 61425 CHIP TRS. 2SC2873(Y) HX328731B0
QH04 4822 130 61425 CHIP TRS. 2SC2873(Y) HX328731B0
QH05 4822 130 42839 FET 2SK369 BL
VDGS-40V PDO.4W
HF203691B0
QH06 4822 130 42839 FET 2SK369 BL
VDGS-40V PDO.4W
HF203691B0
QH07
4822 130 63928 CHIP TRS. 2SA1312(B) HX113121B0
QH12
QP01 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QP02 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QP03 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QP04 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QP05 4822 130 63496 SEMICON.COMP
RN1311 DTC114TU
BA21311000
QP06 17 /F
18A /L,/U
IC STR-G6651
SW.REGULATOR
HC10007080
QP06 7010 /F,/L,/U IC STR-G6651
SW.REGULATOR
HC10007080
